FN063-SDK.4I.V7P1
Brand：
ZIEHL-ABEGG
Category：
Axial Fan
Description：
Type: Axial fan
Air output (m³/h): 11500
Speed (RPM): 1040
Min. operating temperature: -40°C
IP54 protection
Aluminium rotor and blades
Air output (m³/h): 11500
Speed (RPM): 1040
Min. operating temperature: -40°C
IP54 protection
Aluminium rotor and blades
Nominal data
Brand：
ZIEHL-ABEGG
Part No.：
FN063-SDK.4I.V7P1
Fan Type：
Axial Fan
Rated Voltage(V)：
400
Size(mm)：
630
Max.Air Flow(m³/h)：
11500
Max.Pressure(Pa)：
120
Input Power(W)：
1000
Speed(rpm)：
1040
Noise(db)：
67
Description
FN063-SDK.4I.V7P1 Ziehl-Abegg Specification Drawing：
